Manufactured using advanced filament winding technology, our FRP GRP horizontal tank provides superior strength and durability while maintaining excellent chemical resistance. The seamless construction eliminates potential leak points, ensuring the safe containment of hazardous and non-hazardous chemical liquids. We work closely with industrial operators, engineering firms, and project managers to deliver custom horizontal storage solutions that meet your specific project requirements and regulatory standards.
The lightweight nature of FRP/GRP materials significantly reduces transportation and installation costs compared to steel or concrete alternatives. Our corrosion-resistant chemical liquid storage tank requires minimal maintenance and offers a long service life, making it the most cost-effective choice for long-term chemical storage needs.
The low-profile horizontal configuration maximizes storage capacity while minimizing footprint, making it perfect for facilities with limited vertical space. This design also provides excellent stability and reduces wind resistance, making it suitable for installation in high-wind areas.
All our horizontal tanks are manufactured using computer-controlled filament winding technology, which creates a seamless, uniform structure with exceptional tensile strength. This construction method ensures consistent quality and eliminates the weak points associated with welded steel tanks.
Our horizontal FRP tank is suitable for both aboveground and underground installation. For underground applications, we offer additional structural reinforcement to withstand soil pressure and vehicle loads, ensuring safe and reliable operation below ground.
The non-porous FRP material and seamless construction prevent leaks and chemical seepage, protecting the environment from contamination. All tanks are equipped with secondary containment options for added safety and compliance with environmental regulations.
Parameter | Specification Range |
Capacity | 0.5 m³ - 2000 m³ |
Length | 1 m - 30 m |
Diameter | 0.5 m - 4.5 m |
Operating Temperature | -30°C to 110°C |
Operating Pressure | Atmospheric to 0.4 MPa |
Wall Thickness | 5 mm - 40 mm |
Liner Material | Bisphenol-A epoxy vinyl ester resin |
Reinforcement | Continuous E-glass roving |
Surface Finish | Smooth gel coat, anti-slip top surface |
Color | Customizable (standard: white, yellow, red) |
Our aboveground horizontal GRP tank is ideal for storing various chemical liquids including:
Industrial acids and alkalis
Water treatment chemicals
Agricultural fertilizers and pesticides
Food-grade liquids and ingredients
Petroleum products and fuels
Wastewater and effluent
Cleaning agents and detergents
Quality is at the heart of everything we do. Every corrosion-resistant FRP GRP horizontal tank is manufactured in accordance with strict quality management systems and international standards. We conduct comprehensive material testing, dimensional inspections, and hydrostatic pressure tests on all tanks to ensure they meet our rigorous quality requirements. Our products are certified by leading international organizations and comply with all relevant safety and environmental regulations.
Yes, we offer specially designed underground horizontal tanks with additional structural reinforcement to withstand soil pressure and vehicle loads. These tanks are also equipped with corrosion protection for underground environments.
Our standard horizontal tanks are available in capacities up to 2000 m³. For larger storage requirements, we can design and manufacture custom solutions to meet your specific needs.
Yes, we provide a range of secondary containment options including double-walled tanks and external containment basins. These systems provide an additional layer of protection against leaks and spills, ensuring compliance with environmental regulations.
